Chassis

• Ram 5500/ Ford F550

• 203” Wheelbase

• Exterior color: White

• Chassis GVWR 19,500 lbs

• Custom frame extension for longer custom living quarters

• High capacity trailer towing package

• 6.7L Diesel or 7.3 Gas Motor (Ford) or 6.7L Diesel Motor (Ram)

• 74 gallon fuel tank on Ram & 66.5 gallon fuel tank on Ford

• Dual alternators- rated at 440 amps

• 4.88 Ratio Limited Slip rear axle

• Premium sound system

• Backup camera and front park sensors (Ram also has rear sensors)

• Apple CarPlay, Google Android Auto, large infotainment display

• Dual-zone auto temperature control, heated and cooled front seats, heated rear seats

• Buckstop aluminum front bumper with integrated winch mount

• Front receiver hitch

• Adrenalin rear bumper with integrated winch mount and hydraulic spare tire lift

• Stazworks 20" 2 piece wheels

• Goodyear G275 335/80R20(41") tires or Michelin X Force 335/80R20 (41"/43") tires

• ComeUp 20,000 LB front winch with synthetic winch line

• Rigid lights in Front bumper (bumper style determines which style of lights fit)

• 16,500-18,500LB loaded overall weight

•  29’ overall length, 94” overall width, 12’ overall height

• Amp XL automatic power steps

• Speedometer Calibrator

Suspension

• Liquid Springs active smart suspension

• True Earth campsite leveling

• Automatically load levels chassis

• 5 adjustable right height settings

• 3 adjustable ride comfort settings: sport, normal, comfort

Custom Living Space

• Dimensions: 14’ box, 7’ cab overhang, 91” wide, 7’ interior height, 12’ overall height

• All aluminum construction

• Z channel framing for better insulation.

• Extruded 6061 aluminum tube for structure

• Aluminum exterior poly core panels, bonded with 3M VHB

• Spray in foam insulation, 14 R value in walls, 20 R value in floors and ceiling

• Reinforced, walk-on roof

• 3/4” PakTite engineered subfloor, with Commercial Grade Vinyl flooring

• Upholstered interior walls and ceiling panels

• Full aluminum cabinets with internal drawers and automatic LED lighting

• Full aluminum drawers with easy open latches

• Outbound windows and roof hatch, dual pane safety glass, bug & blackout shades

• Outbound entry door with window & screen

• Fiamma electric awning with automatic wind sensor retract

• Rear garage with automatic LED lighting

• Aluminum under-mount storage boxes

• Rigid scene lights on left/right sides and rear

• Tank heaters for fresh and grey water tanks

Electrical

• 24v electrical system

• Mastervolt combimaster 3500w inverter/charger

• C-zone Touch 7 control panel

• 2 Mastervolt MPPT solar controllers

• 2000 total watts of solar on roof

• 2 - Mastervolt 24-6000 batteries

• 460ah at 24v total capacity battery storage

• 2 Mastervolt Mac+ 50 amp DC to DC charger

• Mastervolt Mac+ 50 amp DC to DC 12v converter

• C-zone control X lighting, tank monitor, system control

• C-zone NMEA 2000 network connectivity on all components for monitoring and safety systems

• LED interior lighting

Audio / Visual

• 2 Smart TV’s with wired HDMI and USB (optional)

• JL Audio Media Master 100 Marine Head Unit

• JL Audio 10” Stealth-box Subwoofer

• 4 - JL Audio C2 internal speakers

• 2 - JL Audio External marine grade speakers

• JL Audio XD600/6 amplifier

HVAC

• Cruisin Comfort dual evaporator, 24v air conditioner. 16,000 BTU

• C-zone controller

• 2 - MaxAir roof vent fans (over dinette and bathroom)

• Aqua-Hot Diesel Heater and water heater system

• Outbound large roof hatch

Plumbing / Bathroom

• Aluminum wet bath package

• Thetford 7 gallon cassette toilet

• Vanity mirror with storage

• Heater Craft shower control

• 100 gallon fresh water storage

• 45 gallon grey water storage

• Exterior Shower connection

• Variable speed water pump

Kitchen / Sleeping

• Lightweight bamboo or quartz countertop

• Stainless steel galley sink with strainer/cutting board drop in’s

• Pop up 110/12v charging station in countertop

• Full size pull out kitchen garbage can

• Flush mounted True Induction dual cooktop

• Iceotherm fridge/freezer combo

• Microwave/convection oven combo

• Powered telescoping dinette table base

• Dinette transforms into a queen size bed

• King size bed over cab, custom triple density foam mattress

• Bedside LED gooseneck reading lights with USB charger

• USB, 12v and 120V ac bed-side power

• Bedside storage shelves

• Camp Chef 2 burner stove or Traeger Ranger Pellet Grill (outdoor cooker)
